Side Tilt Carriage - There are 4 sizings of hook type tine carriages rated by the fork carriage lifting capacity. Hook type tine carriages have been the same.
Class I carriages are rated for loads as much as 2000 lbs. The carriage bar spacing for Class I is thirteen inches. Class II carriages are rated for loads up to 5,550 lbs. Their carriage bar spacing is sixteen inches. Class III carriages are rated for cargo as much as 10,000 lbs. The carriage bar spacing for this particular class is 20 inches. Class IV carriages are rated for cargo as much as 15,500 lbs. The carriage bar spacing used for this capacity is twenty five inches.
The carriages for pin type blades can be different depending on the maker. Pin mounted blades could differ by the amount of offset between the blade eye and the fork. Carriage capacity would be determined by the carriage pin size and by the blade size.
